| Product thermal capacity: | 1-20 t/h |
| Working pressure: | 0.7-2 MPa |
| Available fuel: | Natural gas, coke oven gas, biogas, diesel, heavy oil, light oil, crude oil, etc. |
| Available industries: | Heat supplying, chemical, food, textile, printing and dyeing, cigarettes and tobacco, fodder, pharmacy, building materials, brewery, rubber, hospital etc. |
Introduction of 3 Pass Fire Tube Boiler
The WNS Series Gas/Oil Fired 3 Pass Fire Tube Boiler adopts a three-pass design to maximize heat transfer efficiency and reduce fuel consumption. The fire tube configuration ensures optimal combustion, promoting thorough heat exchange and enhancing energy efficiency. It is equipped with an advanced control system to achieve precise temperature and pressure regulation, ensuring safe and stable operation.
Features of 3 Pass Fire Tube Boiler
Efficient and Energy-Saving: The WNS Series Three-Pass Fire Tube Boiler adopts advanced design and optimized heat transfer structure, achieving high efficiency and energy savings. It maximizes the utilization of fuel energy, reduces energy consumption, and decreases operational costs.
Stable and Reliable: This boiler is constructed with sturdy and durable materials, employing excellent manufacturing processes to ensure long-term stable operation. Equipped with an intelligent control system, it achieves precise regulation and automated operation, guaranteeing safe and reliable performance.
Multi-Fuel Adaptability: The WNS Series boiler supports various fuel options, including natural gas, diesel, and heavy oil. Users can choose the appropriate fuel according to their specific requirements, providing greater flexibility and adaptability.
Easy Operation and Maintenance: Designed with user-friendliness in mind, this boiler features an easily operated control panel and accessible components. Maintenance and servicing are relatively simple, minimizing downtime and improving production efficiency.
Specification of 3 Pass Fire Tube Boiler
| Model | Rated steam capacity (t/h) | Rated working pressure (MPa) | Rated steam temperature (℃) | Maximum transport dimension (m) |
| WNS1-0.7-Q(Y) | 1 | 0.7 | 170 | 3.25×1.80×2.00 |
| WNS1-1.0-Q(Y) | 1 | 1 | 184 | 3.25×1.80×2.00 |
| WNS1.5-1.0-Q(Y) | 1.5 | 1 | 184 | 3.65×2.05×2.45 |
| WNS1.5-1.25-Q(Y) | 1.5 | 1.25 | 194 | 3.65×2.05×2.45 |
| WNS2-1.0-Q(Y) | 2 | 1 | 184 | 4.60×2.20×2.60 |
| WNS2-1.25-Q(Y) | 2 | 1.25 | 194 | 4.60×2.20×2.60 |
| WNS3-1.0-Q(Y) | 3 | 1 | 184 | 5.35×2.40×2.80 |
| WNS3-1.25-Q(Y) | 3 | 1.25 | 194 | 5.35×2.40×2.80 |
| WNS4-1.25-Q(Y) | 4 | 1.25 | 194 | 5.00×2.60×2.95 |
| WNS4-1.6-Q(Y) | 4 | 1.6 | 204 | 5.00×2.60×2.95 |
| WNS5-1.25-Q(Y) | 5 | 1.25 | 194 | 5.55×2.658×3.20 |
| WNS5-1.6-Q(Y) | 5 | 1.6 | 204 | 5.55×2.658×3.20 |
| WNS6-1.25-Q(Y) | 6 | 1.25 | 194 | 5.93×2.80×3.20 |
| WNS6-1.6-Q(Y) | 6 | 1.6 | 204 | 5.93×2.80×3.20 |
| WNS8-1.25-Q(Y) | 8 | 1.25 | 194 | 7.00×2.80×3.25 |
| WNS8-1.6-Q(Y) | 8 | 1.6 | 204 | 7.00×2.80×3.25 |
| WNS10-1.25-Q(Y) | 10 | 1.25 | 194 | 7.65×2.80×3.25 |
| WNS10-1.6-Q(Y) | 10 | 1.6 | 204 | 7.65×2.80×3.25 |
| WNS15-1.25-Q(Y) | 15 | 1.25 | 194 | 7.95×3.50×3.75 |
| WNS15-1.6-Q(Y) | 15 | 1.6 | 204 | 7.95×3.50×3.75 |
| WNS20-1.25-Q(Y) | 20 | 1.25 | 194 | 8.55×3.90×4.15 |
| WNS20-1.6-Q(Y) | 20 | 1.6 | 204 | 8.55×3.90×4.15 |
