| Product thermal capacity: | 1.4 – 7 MW |
| Working pressure: | 1.0-1.6 MPA |
| Outlet temperature: | 115/70 ℃ |
| Available fuel: | Biomass molding granules, wood chip, corn cob, palm shell |
| Available industries: | Heating, hotels, schools, hospitals |
Introduction of DZL series biomass-fired hot water boiler
The DZL series quick-installed boiler is a horizontal three-pass water-fire tube chain grate boiler designed for biomass combustion. The boiler features a single drum layout with threaded smoke tubes for convective heating surface, and water-cooled walls on both sides of the drum for radiant heating surface. The combustion equipment adopts a lightweight chain grate, and the boiler is delivered in a complete quick-installed form. The electrical control system enables infinitely variable control of the grate, with alarm and interlock protection for critical parameters.
Feature of DZL series biomass-fired hot water boiler
1.Arched tube sheets and threaded fire tube was first adopted in China to increase heat transfer and completely solve the problem of cracking of the back tube sheet.
2.The welding of smoke tube and the tube plate adopts pre-expansion to eliminate the gap between the tube and tube plate, then be welded by automatic argon arc welding, which effectively eliminate stress and prolong boiler life.
3.The independent secondary fan makes it easy to control and adjust the wind volume and pressure.
Why choose us
1. Our uniquely customized system solutions deliver maximum energy efficiency and low emissions
2. State of the art computer, variable frequency and video monitoring systems are in place to ensure the safe operation of our boliers
3. Agreeable design of outer casings and a wide choice of colors to your order
4. Our dedicated service team of experts and professionals is 24/7 available online to provide you with the best technical support
