Principle of oil-fired steam boiler in Pakistan is using fuel oil, including diesel oil, waste oil and other oils. The general arrangement of oil fired boilers are similar to that of coal-fired boilers, except that the bottom of the oil fired boiler chamber is mostly made into an insulated bottom that is inclined 10° to 30° to the back wall to obtain good combustion characteristics. In order to make the fuel oil can be atomized, there are two types of oil burner nozzles: mechanical centrifugal nozzle and steam atomized Y-type nozzle.
ZOZEN oil-fired steam boiler include oil-fired hot water boilers, oil-fired heating boilers, oil-fired bathing boilers, oil-fired steam boilers, etc..Compared with gas fired boilers and electric heating boilers, oil fired boilers are more economical to run than electric heating boilers and easier to use than gas fired boilers.
The main structure of oil-fired steam boiler adopts combined-type quick installation structure, with compact and reasonable layout, light weight, less occupation of space, simple and quick installation and convenient maintenance. The low and symmetrical arrangement of the combustion chamber increases the safe water level range of the steam boiler and can reduce the harm of water shortage accident to the greatest extent.
The front and rear tube-plates of oil-fired steam boiler are all flat tube-plates with flanged edges. Tube-plates, barrel bodies, furnace bile and back-combustion chamber are butt-welded with flanged edges with low thermal stress. The smoke pipes of the second and third flow of the boiler are arranged in order and symmetrically with the furnace tube as the center, which can improve the stress condition of the front and rear tube plates. Bevel edge butt welding and full wet back structure are of great benefit to improve boiler operating environment, increase boiler efficiency and prolong boiler service life.
This series of industrial boilers adopt corrugated furnace tube, the optimized combination form of threaded tube and light tube in convection zone, the flue gas flow is long, the heat transfer effect is good and the boiler volume is reduced. The carefully designed smoke box adopts double sealing structure to ensure the sealing of smoke. The double door structure is convenient for maintenance.
Oil-fired boiler is equipped with original imported burner with strong power to ensure boiler output and suitable for all kinds of oil and fuel. Complete set of equipment, a full set of equipment by the boiler body, burners, intelligent control devices, valve instruments and other components, but also equipped with high-performance water pump. Welcome everyone to come to consult purchasing, ZOZEN Boiler will serve you wholeheartedly.
